Industrial Roller Type Magnetic Separators

Industrial Roller Type Magnetic Separators
Industrial Roller Type Magnetic Separators
Send Inquiry
Product Code : 15
Product Description

With our expertise in this domain we are offering a superior quality range of Industrial Roller Type Magnetic Separators that incorporates high energy rare earth neodymium permanent magnetic roll assembly. The offered product is featured with the high efficiency of the iron separation system & vibratory feeder with controls provided for feeding. Our Industrial Roller Type Magnetic Separators find usage in industries like minerals applications such as abrasive, refractory and ceramic raw material beneficiation, carbide, magnesite, alumina, silica & quartzite.

Roller Type Magnetic Separators

Features:

Magnetic Rolls available in 65, 75 & 100mm Dia. & widths up to 1200mm. In three different Magnetic Strengths 8,000 Gauss, 20,000 Gauss and 22,000 Gauss. A 0.5 HP, variable speed DC/AC Geared Motor drive adjustable from 0 to 100 RPM Drives the Roll. Vibratory Feeder with Controls provided for Feeding. Abrasion resistant endless conveyor Belts with thickness of 0.8mm is provided for the Machine.
